Actual Product May Vary From Image

035766 DOD

Name: 035766 DOD
Brand: Dodge
SKU: 035766 DOD
Availability: OutOfStock

P2B515-USAF-207LERAH USAF

Manufacturer: Dodge

Manufacturer part number: 035766

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

Price on Request

Qty:

Product Details

Base to Center Height:	3.2500
Base to Center Height (Unit):	INCH
Bearing Component:	Mounted Bearing
Bearing Type:	Spherical Roller
Bolt Diameter:	0.6250
Bolt Diameter (Unit):	INCH
Bolt to Bolt (Max):	9.6300
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	8.6300
Bolt to Bolt (Min) (Unit):	INCH
Bore Length:	4.4700
Bore Length (Unit):	INCH
Dynamic Load Capacity:	48000
Dynamic Load Capacity (Unit):	POUND_FORCE
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Housing Construction:	Split
Housing Dimensional Standard:	SAF
Housing Material:	Cast Iron
Housing Type:	Two-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	3400
Maximum Speed (Unit):	RPM
Seal Type:	Labyrinth
Sensor Ready:	Yes
Shaft Attachment:	Tapered Adapter
Shaft Diameter:	2.4375
Shaft Diameter (Unit):	INCH
Static Load Capacity:	53000
Static Load Capacity (Unit):	POUND_FORCE
