Actual Product May Vary From Image

035782 DOD

Name: 035782 DOD
Brand: Dodge
SKU: 035782 DOD
Availability: OutOfStock

P4B518-USAF-303LERAH USAF

Manufacturer: Dodge

Manufacturer part number: 035782

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

Price on Request

Qty:

Product Details

Base to Center Height:	4.0000
Base to Center Height (Unit):	INCH
Bearing Component:	Mounted Bearing
Bearing Type:	Spherical Roller
Bolt Diameter:	0.6250
Bolt Diameter (Unit):	INCH
Bolt to Bolt (Max):	11.6300
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	10.3800
Bolt to Bolt (Min) (Unit):	INCH
Bolt Width:	2.1300
Bolt Width (Unit):	INCH
Bore Length:	5.7000
Bore Length (Unit):	INCH
Dynamic Load Capacity:	78000
Dynamic Load Capacity (Unit):	POUND_FORCE
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Housing Construction:	Split
Housing Dimensional Standard:	SAF
Housing Material:	Cast Iron
Housing Type:	Four-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	2600
Maximum Speed (Unit):	RPM
Seal Type:	Labyrinth
Sensor Ready:	Yes
Shaft Attachment:	Tapered Adapter
Shaft Diameter:	3.1875
Shaft Diameter (Unit):	INCH
Static Load Capacity:	85000
Static Load Capacity (Unit):	POUND_FORCE
