Actual Product May Vary From Image

069522 DOD

Name: 069522 DOD
Brand: Dodge
SKU: 069522 DOD
Price: 697.41 USD
Availability: OutOfStock

P4B-IP-208R

Manufacturer: Dodge

Manufacturer part number: 069522

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

$697.41

Qty:

Product Details

Base to Center Height:	2.7500
Base to Center Height (Unit):	INCH
Bearing Component:	Mounted Bearing
Bearing Type:	Spherical Roller
Bolt Diameter:	0.5000
Bolt Diameter (Unit):	INCH
Bolt to Bolt (Max):	7.3100
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	6.9400
Bolt to Bolt (Min) (Unit):	INCH
Bolt Width:	1.7500
Bolt Width (Unit):	INCH
Bore Length:	3.4200
Bore Length (Unit):	INCH
Dynamic Load Capacity:	39000
Dynamic Load Capacity (Unit):	POUND_FORCE
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Grease Name:	MobilGrease XHP222
Housing Construction:	Solid
Housing Dimensional Standard:	S-2000
Housing Material:	Cast Iron
Housing Type:	Four-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	2400
Maximum Speed (Unit):	RPM
Seal Type:	Triple-Lip Contact
Sensor Ready:	Yes
Shaft Attachment:	Push-Pull Adapter
Shaft Diameter:	2.5000
Shaft Diameter (Unit):	INCH
Static Load Capacity:	47500
Static Load Capacity (Unit):	POUND_FORCE
Take-Up Frame Size:	HD-200
