074093406 HWD

Wiring Device-Kellems Kellems Wire Management S-TITE 074093406 Non-Insulated Straight Male Metallic Liquidtight Connector, 1-1/2 in Trade, Steel
Manufacturer part number: 074093406
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$135.83

Product Details

Brand Name

Wiring Device-Kellems

Type

Flexible Non-Insulated Straight

Description

Kellems® liquid tight, flexible metal conduit grips are offered with high quality Hubbell® plated steel fittings in a wide variety of NPT sizes and configurations, either insulated or non-insulated. The addition of a stainless steel mesh to these fittings makes them stronger than the conduit itself. Kellems® conduit grips helps prevent conduit pull-out from the connecting fitting that is subject to stress, pull tension, vibration, motion or strain. They promote safe electrical systems and reduce equipment downtime.
Wiring Device-Kellems Kellems Wire Management S-TITE Liquidtight Connector, Non-Insulated Straight Male Metallic, 1-1/2 in Trade, 1.53 in Throat, For Use With: PolyTuff® I Non-Metallic and Liquid Tight Metal Conduit, Surface Mounting, Steel, Metallic, 2.21 in L x 2.72 in W Dimensions

Application

For hazardous locations and preventing conduit pull-out and damage at the fitting

Standards

CSA Certified | Hazardous Location per Class 1 Division 2, Class II Division 1, 2 Class III Division 1, 2 | UL File No. 898D | UL File No. 899D | UL File No. 94 HB/94 V-2 Flammability Rated

Features

  • Reduces equipment downtime
  • Stainless steel strand
  • Nylon shell construction
  • Zinc plated steel ferrule and locknut
  • -34 to 107 deg C operating temperature
  • 1.969 to 2.016 in recommended knockout hole
  • Mounts between enclosure and conduit
  • 1.53 in Dia throat
  • Suitable for use in wet locations when a listed sealing ring is used between box and fitting

Includes

Stainless Steel Mesh

Specifications

Cable Openings:6-3/4 in
Color:Metallic
Country of Origin:US
Dimensions:2.21 in L x 2.5 in W
Finish:Zinc Plated
Material:Steel
Mounting Type:Surface
Suitable For Use With:PolyTuff® I Liquid Tight Non-Metallic Conduit and Type B Metallic
Throat Size:1.53 in
Trade Size:1-1/2 in
