Actual Product May Vary From Image

074652 DOD

Name: 074652 DOD
Brand: Dodge
SKU: 074652 DOD
Price: 982.10 USD
Availability: OutOfStock

P2B-GTAH-15-HT

Manufacturer: Dodge

Manufacturer part number: 074652

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

$982.10

Qty:

Product Details

Ball Bearing Series:	215 Series
Base to Center Height:	3.5000
Base to Center Height (Unit):	INCH
Bearing Type:	Ball
Bolt to Bolt (Max):	9.5000
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	8.5000
Bolt to Bolt (Min) (Unit):	INCH
Bore Length:	2.7200
Bore Length (Unit):	INCH
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Grease Name:	Krytox GPL 206
Housing Construction:	Solid
Housing Material:	Cast Iron
Housing Type:	Two-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	3200
Maximum Speed (Unit):	RPM
Seal Type:	Labyrinth
Sensor Ready:	Adapter Required
Shaft Attachment:	Push-Pull Adapter
Standoff Housing:	No
Suitable for High Temperature:	Yes
Suitable For Washdown:	No
Take-Up Frame Size:	LD-50,TS-350
