077276 DOD

Name: 077276 DOD
Brand: Dodge
SKU: 077276 DOD
Price: 1,845.21 USD
Availability: OutOfStock

Actual Product May Vary From Image

Manufacturer:

Manufacturer part number:

077276

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

$1,845.21 / EA

Description

Base to Center Height:	3.7500
Base to Center Height (Unit):	INCH
Bearing Type:	Tapered Roller
Bolt Diameter:	0.7500
Bolt Diameter (Unit):	INCH
Bolt to Bolt (Max):	11.7500
Bolt to Bolt (Max) (Unit):	INCH
Bolt to Bolt (Min):	10.5600
Bolt to Bolt (Min) (Unit):	INCH
Bolt Width:	2.3800
Bolt Width (Unit):	INCH
Bore Length:	5.0000
Bore Length (Unit):	INCH
Expansion Capability:	Non-Expansion (Fixed)
Greasable:	Yes
Grease Name:	MobilGrease XHP222
Housing Construction:	Split
Housing Dimensional Standard:	Type E
Housing Material:	Ductile Iron
Housing Type:	Four-Bolt Pillow Block
Insert Material:	Steel
Lubrication:	Grease
Maximum Speed:	1640
Maximum Speed (Unit):	RPM
Seal Type:	Triple-Lip Contact
Sensor Ready:	Yes
Shaft Attachment:	Setscrew
Shaft Diameter:	3.4375
Shaft Diameter (Unit):	INCH
Static Load Capacity:	108600
Static Load Capacity (Unit):	POUND_FORCE
Take-Up Frame Size:	HD-350,TS-400
