Picture of 100 HUB RND SS 1-7/8 1/2X1/4K LOV
Actual Product May Vary From Image

100 HUB RND SS 1-7/8 1/2X1/4K LOV

Lovejoy® 68514439546 Deltaflex Finished Bore Round Flex Link Coupling Hub With (2) Setscrews, 100 Coupling, 1-7/8 in Dia Bore, 3.88 in L Through Bore, 7-1/4 in Dia Hub, Stainless Steel
Manufacturer: Lovejoy
Manufacturer part number: 68514439546
Availability: Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
Price on Request

Product Details

Brand Name

Lovejoy®

Type

Finished Bore Round

Description

Lovejoy® Flex Link Coupling Hub, Finished Bore Round, Series: Deltaflex, 100 Coupling, 1-7/8 in Bore, 7-1/4 in Diameter Hub, 3.88 in Hub Length, 1/2 in W x 1/4 in D Keyway, 3.88 in Length Through Bore, 1/2-13 Screw, Stainless Steel, Metallic

Application

Compressors, Pumps, Fans, Positioning Devices, Indexing Tables, Mixers, Papermill Roll Drives, Drive Line Shafts, Turbine Drives, Wind Tunnels, Cooling Towers and Single Bearing Generator Drives Applications

Standards

ACMA Certified | ECCN EAR99 | EPTDA Approved | FPDA Motion and Control Network Member | Member of Hydraulic Institute | MPTA Standard | NFPA Member | PTDA Approved

Features

  • Maximum misalignment capabilities, with negligible reactionary load, for longer equipment bearing life
  • Operates as smoothly when misaligned as when perfectly aligned
  • No lubrication and no maintenance required
  • Equipment can be visually aligned
  • No special tools are required, which saves on installation time and cost
  • Eliminates premature equipment bearing and seal failure resulting from misalignment forces
  • This means greater equipment productivity
  • Torsionally stiff coupling with no backlash means it is capable of high speed applications, within catalog ratings
  • Provides long-term performance and economy

Specifications

Bore Diameter:1-7/8 in
Country of Origin:US
Coupling Size:100
Finish:Metallic
Hub Diameter:7-1/4 in
Hub Length:3.88 in
Keyway Size:1/2 in W x 1/4 in D
Length Through Bore:3.88 in
Material:Stainless Steel
Screw Size:1/2-13
Series:Deltaflex
