100 HUB RND SS 4-1/8 1X1/2KW LOV

Name: 100 HUB RND SS 4-1/8 1X1/2KW LOV
Brand: Lovejoy
SKU: 100 HUB RND SS 4-1/8 1X1/2KW LOV
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Lovejoy

Manufacturer part number:

68514439564

CBT Inventory

Vendor Inventory

Availability:

Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Lovejoy®

Type

Finished Bore Round

Description

Lovejoy® Flex Link Coupling Hub, Finished Bore Round, Series: Deltaflex, 100 Coupling, 4-1/8 in Bore, 7-1/4 in Diameter Hub, 3.88 in Hub Length, 1 in W x 1/2 in D Keyway, 3.88 in Length Through Bore, 1/2-13 Screw, Stainless Steel, Metallic

Application

Compressors, Pumps, Fans, Positioning Devices, Indexing Tables, Mixers, Papermill Roll Drives, Drive Line Shafts, Turbine Drives, Wind Tunnels, Cooling Towers and Single Bearing Generator Drives Applications

Standards

Features

Maximum misalignment capabilities, with negligible reactionary load, for longer equipment bearing life
Operates as smoothly when misaligned as when perfectly aligned
No lubrication and no maintenance required
Equipment can be visually aligned
No special tools are required, which saves on installation time and cost
Eliminates premature equipment bearing and seal failure resulting from misalignment forces
This means greater equipment productivity
Torsionally stiff coupling with no backlash means it is capable of high speed applications, within catalog ratings
Provides long-term performance and economy

Specifications

Bore Diameter:	4-1/8 in
Country of Origin:	US
Coupling Size:	100
Finish:	Metallic
Hub Diameter:	7-1/4 in
Hub Length:	3.88 in
Keyway Size:	1 in W x 1/2 in D
Length Through Bore:	3.88 in
Material:	Stainless Steel
Screw Size:	1/2-13
Series:	Deltaflex
