Actual Product May Vary From Image

120F54 MSG

Name: 120F54 MSG
Brand: Martin Sprocket & Gear
SKU: 120F54 MSG
Price: 1,060.92 USD
Availability: OutOfStock

Martin 120F54 Type C Single Strand Stock Bore Welded Roller Chain Sprocket With Lightening Holes, 3-15/16 in Dia Bore, 26.654 in OD, #120 Chain, 54 Teeth, 1-1/2 in Pitch, Steel

Manufacturer: Martin Sprocket & Gear

Manufacturer part number: 120F54

Availability: Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$1,060.92

Qty:

Product Details

Brand Name

Martin

Type

Type C Single Strand Stock Bore Welded

Description

QD® (Quick Detachable) is a sprocket where a tapered bushing is bolted into the taper bore that is machined in the sprocket. When installed this bushing is compressed onto the shaft providing a tight grip.

Martin Roller Chain Sprocket, Type C Single Strand Stock Bore Welded, 3-15/16 in Bore, 26.654 in OD, #120 Chain, 54 Teeth, 1-1/2 in Pitch, 25.798 in Pitch Diameter, 7 in Diameter Hub, 3-5/8 in Length Through Bore, QD® F Bushing, Steel

Standards

Features

Without hardened teeth

Specifications

Bore Diameter:	3-15/16 in
Bushing Type:	QD® F
Chain Size:	#120
Country of Origin:	US
Hub Diameter:	7 in
Length Through Bore:	3-5/8 in
Material:	Steel
Number of Teeth:	54
Outside Diameter:	26.654 in
Pitch:	1-1/2 in
Pitch Diameter:	25.798 in
