Actual Product May Vary From Image

120TB45 BRN

Name: 120TB45 BRN
Brand: Regal Rexnord
SKU: 120TB45 BRN
Availability: OutOfStock

Browning® 3789070 Single Strand Roller Chain Sprocket, 15/16 in Dia Bore, 22.365 in OD, #120 Chain, 45 Teeth, 1 in Pitch, Steel

Manufacturer: Regal Rexnord

Manufacturer part number: 3789070

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

Browning®

Type

Single Strand

Description

Browning® offers a variety of bushing type sprockets available in single and double strands. Offerings include 35 to 160 pitch range. Bushed type bore ranges are available from 1/2 to 5 in. Hardened teeth are available up to 30 teeth.

Browning® Roller Chain Sprocket, Single Strand, 15/16 in Bore Dia, 22.365 in Outside Dia, #120 Chain, 45 Teeth, 1 in Pitch, 21.503 in, 7.145 in Hub Dia, 3 in Length Through Bore, Type 1 Taper Bore Bushing, Steel

Application

Aggregate, Cement, Agriculture, Forestry, Minerals, Mining, Pulp and Paper Industries

Standards

ANSI Specified

Features

This product has the Browning® exclusive twice the life guarantee
Compact design
Hardened teeth at no extra cost, drives sizes up to 30 teeth on 40 through 160 chain
1-11/16 in/ft taper
Setscrew or cap screw acts as external key
Flush fit, less space on shaft
No protruding flange
For use with 1 in pitch ANSI chain

Specifications

Bore Diameter:	15/16 in
Bushing Type:	Type 1 Taper Bore
Chain Size:	#120
Country of Origin:	CN
Hub Diameter:	7.145 in
Length Through Bore:	3 in
Material:	Steel
Number of Teeth:	45
Outside Diameter:	22.365 in
Pitch:	1 in
Pitch Diameter:	21.503 in
