124173 DOD

Picture of 124173 DOD
Actual Product May Vary From Image

Product Details

Manufacturer:
Dodge
Manufacturer part number:
124173
CBT Inventory
22
Vendor Inventory
Loading...
CBT - CINCINNATI
13
CBT - SPRINGBORO
2
CBT - SIDNEY
5
CBT - LEXINGTON
2
CBT - LOUISVILLE
0
Availability:
22 in stock
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$95.13 / EA

Description

Specifications

Ball Bearing Series:205 Series
Bearing Type:Ball
Bolt Diameter:0.4375
Bolt Diameter (Unit):INCH
Bolt to Bolt (Max):3.8900
Bolt to Bolt (Max) (Unit):INCH
Bolt to Bolt (Min):3.8900
Bolt to Bolt (Min) (Unit):INCH
Bore Length:1.3400
Bore Length (Unit):INCH
Dynamic Load Capacity:3146
Dynamic Load Capacity (Unit):POUND_FORCE
Expansion Capability:Non-Expansion (Fixed)
Greasable:Yes
Grease Name:Unirex N2
Housing Construction:Solid
Housing Material:Cast Iron
Housing Type:Two-Bolt Flange
Insert Material:Steel
Lubrication:Grease
Maximum Speed:4500
Maximum Speed (Unit):RPM
Seal Type:Single-Lip Contact
Sensor Ready:Adapter Required
Shaft Attachment:Setscrew
Shaft Diameter:1.0000
Shaft Diameter (Unit):INCH
Standoff Housing:No
Static Load Capacity:1769
Static Load Capacity (Unit):POUND_FORCE
Suitable for High Temperature:No
Suitable For Washdown:No

Resources

Tech BulletinEngineering DrawingInstallation

Products Specifications

Brand Name
ABB
Measuring Units
Inch
Shaft Diameter
1 in
