Actual Product May Vary From Image

14585 90010 TKN

Name: 14585 90010 TKN
Brand: Timken
SKU: 14585 90010 TKN
Availability: OutOfStock

Timken® 14585-90010 Type TS Tapered Roller Bearing, 1-3/8 in Dia Bore, 2-11/16 in OD, 1 Row, 13/16 in W, 13300 lb Dynamic/15300 lb Static Load

Manufacturer: Timken

Manufacturer part number: 14585-90010

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

Timken®

Type

Type TS

Description

TS single row is the basic and the most widely used type of tapered roller bearing. It consists of the inner-ring assembly and the outer ring. It is usually fitted as one of an opposing pair. During equipment assembly, single-row bearings can be set to the required clearance endplay or preload condition to optimize performance.

Timken® Tapered Roller Bearing, Type TS, 1-3/8 in Bore Dia, 2-11/16 in Outside Dia, 1 Rows, 13/16 in Width, 13300 lb Dynamic/15300 lb Static, Steel Bearing, Stamped Steel Cage, -65 to 250 deg F

Application

Vehicle Front Wheels, Differential and Pinion Configurations, Conveyor Rolls, Machine Tool Spindles, Trailer Wheels and General Purpose Applications

Standards

ABMA/ANSI Standard

Features

Internal geometry provides increased stiffness and exceptional runout
Radial runout high point marked for accurate installation

Includes

(1) 14585 13/16 in W Cone and (1) 5/8 in W Cup

Specifications

Bearing Material:	Steel
Bore Diameter:	1-3/8 in
Cage Material:	Stamped Steel
Load Capacity:	13300 lb Dynamic/15300 lb Static
Number of Rows:	1
Outside Diameter:	2-11/16 in
Temperature Rating:	-65 to 250 deg F
Width:	13/16 in
