Actual Product May Vary From Image

16007-A-C3 INA

Name: 16007-A-C3 INA
Brand: INA
SKU: 16007-A-C3 INA
Availability: OutOfStock

FAG 16007-A-C3 160 Series Deep Groove Ball Bearing, 35 mm Dia Bore, 62 mm OD, 1 Row, 9 mm W, 13000 N Dynamic/8800 N Static/445 N Fatigue Load

Manufacturer: INA

Manufacturer part number: 16007-A-C3

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

FAG

Description

FAG Deep Groove Ball Bearing, Series: 160 Series, 35 mm Bore Dia, 62 mm Outside Dia, 1 Row, 9 mm W, Open Closure, 13000 N Dynamic/8800 N Static/445 N Fatigue, Steel Cage, 16700 rpm Maximum, 120 deg C, Uncoated

Standards

Meets to DIN 625-1

Features

C3 radial internal clearance

Specifications

Bore Diameter:	35 mm
Cage Material:	Steel
Closure Type:	Open
Finish:	Uncoated
Load Capacity:	13000 N Dynamic/8800 N Static/445 N Fatigue
Maximum Speed:	16700 rpm
Number of Rows:	1
Outside Diameter:	62 mm
Series:	160 Series
Temperature Rating:	120 deg C
Width:	9 mm
