Picture of 170M7031 BSF
Actual Product May Vary From Image

170M7031 BSF

Bussmann 170M7031 High Speed Fuse, 1100 A, 17.5 kV, 125 kA Interrupt, Square Body
Manufacturer: Bussmann
Manufacturer part number: 170M7031
Availability: Expected Leadtime 53 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...
Price on Request

Product Details

Brand Name

Bussmann

Description

Bussmann High Speed Fuse, Indicating/Non-Indicating: Non-Indicating, 1100 A, 17.5 kV, 125 kA Interrupt, Square Body, 12 mm L x 132.5 mm W Body Size

Application

DC Common Bus, DC Drives, Power Converters, Rectifiers and Reduced Voltage Starters Applications

Standards

CE Certified | IEC 60269 | UL Listed

Features

  • Package Type: Standard
  • Watt Losses: 200 W
  • Clearing (I2T): 1500000 at 1000V
  • Connection Type: Din 43 to 620 Blade End x Din 43 to 620 Blade End
  • Width: 4.5 in
  • Barrel Type: Single
  • Weight: 7.107 lbs
  • Length: 5.125 in
  • Pre Arc (I2T): 250000
  • Height: 3.25 in
  • Indicator: Non-Indicating

Specifications

Amperage Rating:1100 A
Body Size:12 mm L x 132.5 mm W
Country of Origin:HU
Indicating/Non-Indicating:Non-Indicating
Interrupt Rating:125 kA
Voltage Rating:17.5 kV
