Actual Product May Vary From Image

17Q15R56 DOD

Name: 17Q15R56 DOD
Brand: Dodge
SKU: 17Q15R56 DOD
Price: 805.65 USD
Availability: OutOfStock

17Q15R56 TIGEAR-2 REDUCER

Manufacturer: Dodge

Manufacturer part number: 17Q15R56

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

$805.65

Qty:

Product Details

Specifications

Base to Output Center Height:	1.9900
Base to Output Center Height (Unit):	INCH
Case Size:	17
Center Distance:	1.7500
Center Distance (Unit):	INCH
Center to End of Shaft Distance:	4.3100
Center to End of Shaft Distance (Unit):	INCH
Horsepower Rating Input:	1.2700
Horsepower Rating Input (Unit):	HORSEPOWER
Horsepower Rating Output:	1.0800
Horsepower Rating Output (Unit):	HORSEPOWER
Housing Material:	Cast Iron
Input Style:	Quill
Lubrication:	PAG, Standard Temperature
Motor Compatibility:	NEMA Motor, 56C Frame
Mounting Bolt Pattern Length:	4.1900
Mounting Bolt Pattern Length (Unit):	INCH
Mounting Bolt Pattern Width:	2.7500
Mounting Bolt Pattern Width (Unit):	INCH
Nominal Ratio:	15.0000
Output Shaft Center to Input Motor Mounting Face Distance:	4.9000
Output Shaft Center to Input Motor Mounting Face Distance (Unit):	INCH
Output Style:	Right
Overhung Load:	1190
Overhung Load (Unit):	POUND_FORCE
Paint Type:	Standard
Rated Torque Output:	583
Rated Torque Output (Unit):	INCH_POUND
Seal Type:	Single-Lip Contact
Shaft Diameter Output:	0.8750
Shaft Diameter Output (Unit):	INCH
Shaft Length Output:	1.7400
Shaft Length Output (Unit):	INCH
Suitable For Washdown:	No
Thermal Horsepower Rating:	2.0100
Thermal Horsepower Rating (Unit):	HORSEPOWER

Resources

Installation
