Actual Product May Vary From Image

17S05LIL113 DOD

Name: 17S05LIL113 DOD
Brand: Dodge
SKU: 17S05LIL113 DOD
Availability: OutOfStock

TIGEAR-2 REDUCER-SPEC I/P SHAFT

Manufacturer: Dodge

Manufacturer part number: 17S05LIL113

Estimated dates are contingent upon manufacturer stock.

Please login to see accurate availability

Price on Request

Qty:

Product Details

Base to Output Center Height:	1.9900
Base to Output Center Height (Unit):	INCH
Case Size:	17
Center Distance:	1.7500
Center Distance (Unit):	INCH
Center to End of Shaft Distance:	4.3100
Center to End of Shaft Distance (Unit):	INCH
Horsepower Rating Input:	2.5900
Horsepower Rating Input (Unit):	HORSEPOWER
Horsepower Rating Output:	2.3900
Horsepower Rating Output (Unit):	HORSEPOWER
Housing Material:	Cast Iron
Input Style:	Separate
Lubrication:	PAG, Standard Temperature
Mounting Bolt Pattern Length:	4.1900
Mounting Bolt Pattern Length (Unit):	INCH
Mounting Bolt Pattern Width:	2.7500
Mounting Bolt Pattern Width (Unit):	INCH
Nominal Ratio:	5.0000
Output Style:	Left
Overhung Load:	1050
Overhung Load (Unit):	POUND_FORCE
Paint Type:	Standard
Rated Torque Output:	430
Rated Torque Output (Unit):	INCH_POUND
Seal Type:	Single-Lip Contact
Shaft Diameter Input:	0.6250
Shaft Diameter Input (Unit):	INCH
Shaft Diameter Output:	0.8750
Shaft Diameter Output (Unit):	INCH
Shaft Length Input:	1.8200
Shaft Length Input (Unit):	INCH
Shaft Length Output:	1.7400
Shaft Length Output (Unit):	INCH
Suitable For Washdown:	No
Thermal Horsepower Rating:	3.9700
Thermal Horsepower Rating (Unit):	HORSEPOWER
