Actual Product May Vary From Image

2082B14 UST

Name: 2082B14 UST
Brand: US Tsubaki
SKU: 2082B14 UST
Price: 188.25 USD
Availability: OutOfStock

Tsubaki® 2082B14 Conveyor Large Type B Double Pitch Roller Chain Sprocket, 1-3/8 in Dia Bore, 9.96 in OD, C2082 Chain, 14 Teeth, 2 in Pitch, Carbon Steel

Manufacturer: US Tsubaki

Manufacturer part number: 2082B14

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$188.25

Qty:

Product Details

Brand Name

Tsubaki®

Type

Large Type B

Alternate Supplier #

Applied Industrial Technologies - 105102328
Motion Industries - 02295136

Description

Tsubaki® Double Pitch Roller Chain Sprocket, Large Type B, Series: Conveyor, 1-3/8 in Bore Dia, 9.96 in Outside Dia, C2082 Chain, 14 Teeth, 2 in Pitch, 8.988 in, 4-3/4 in Hub Dia, 5/16 in Screw, 5/16 x 5/32 in Keyway, 1-7/8 in Length Through Bore, Carbon Steel, Black Oxide

Application

For C2082 chain

Standards

ISO 9001:2000 | ISO 14001 Certified

Specifications

Bore Diameter:	1-3/8 in
Chain Size:	C2082
Country of Origin:	CN
Finish:	Black Oxide
Hub Diameter:	4-3/4 in
Keyway Size:	5/16 x 5/32 in
Length Through Bore:	1-7/8 in
Material:	Carbon Steel
Number of Teeth:	14
Outside Diameter:	9.96 in
Pitch:	2 in
Pitch Diameter:	8.988 in
Screw Size:	5/16 in
Series:	Conveyor
