Actual Product May Vary From Image

20KR85 BSF

Name: 20KR85 BSF
Brand: Bussmann
SKU: 20KR85 BSF
Availability: OutOfStock

Bussmann 20KR85 Non-Indicating Cartridge Fuse, 415 VAC, 20 A

Manufacturer: Bussmann

Manufacturer part number: 20KR85

Availability: Expected Leadtime 30 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

Price on Request

Qty:

Product Details

Brand Name

Bussmann

Type

Non-Indicating

Description

Eaton's Bussmann British standard fuses can be used in multiple applications; industrial, utility, street lighting and domestic. Full range of rated current, voltage available as well as compatible fuse holders. They meet the BS88 part 1 and 2 and IEC 60269-1 and -2 standards.

Bussmann Cartridge Fuse, Non-Indicating, 415 VAC, 20 A, 45 to 62 Hz, Rated Breaking Capacity: 33 kA, Holder Mount, 23 mm Dia x 57 mm L

Standards

RoHS Compliant

Features

Package Type: Standard
Width: 3.543 in
Weight: 0.125 lbs
Length: 45.276 in
Height: 2.362 in
Indicator: Non-Indicating

Specifications

Amperage Rating:	20 A
Country of Origin:	GB
Dimensions:	23 mm Dia x 57 mm L
Frequency Rating:	45 to 62 Hz
Mounting Type:	Holder
Rated Breaking Capacity:	33 kA
Voltage Rating:	415 VAC
