Actual Product May Vary From Image

2206-TVH-C3 FAG

Name: 2206-TVH-C3 FAG
Brand: INA
SKU: 2206-TVH-C3 FAG
Price: 108.55 USD
Availability: OutOfStock

FAG 2206-TVH-C3 22..-K Self-Aligning Ball Bearing, 30 mm Dia Bore, 62 mm OD, 20 mm W, 26000 N Dynamic/6900 N Static/425 N Fatigue Load

Manufacturer: INA

Manufacturer part number: 2206-TVH-C3

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$108.55

Qty:

Product Details

Brand Name

FAG

Description

FAG Self-Aligning Ball Bearing, Series: 22..-K, 30 mm Bore Dia, 62 mm Outside Dia, 20 mm W, Open Closure, 26000 N Dynamic/6900 N Static/425 N Fatigue, Polyamide 66 Cage, 11500 rpm Maximum, 120 deg C, Uncoated

Standards

Meets to DIN 630

Features

Solid cage made from glass fiber reinforced polyamide 66
Radial internal clearance larger than normal

Specifications

Bore Diameter:	30 mm
Cage Material:	Polyamide 66
Closure Type:	Open
Finish:	Uncoated
Load Capacity:	26000 N Dynamic/6900 N Static/425 N Fatigue
Maximum Speed:	11500 rpm
Outside Diameter:	62 mm
Series:	22..-K
Temperature Rating:	120 deg C
Width:	20 mm
