Actual Product May Vary From Image

30-1261J IDE

Name: 30-1261J IDE
Brand: Ideal Industries
SKU: 30-1261J IDE
Price: 0.94 USD
Availability: OutOfStock

IDEAL® WEATHERPROOF® 30-1261J 61® Series Wire Connector, Swept Wing/Twist-On Shell, Live Action/Square Wire Spring, 22 to 14 AWG Solid/Stranded Copper Wire, Thermoplastic Polyester

Manufacturer: Ideal Industries

Manufacturer part number: 30-1261J

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$0.94

Qty:

Product Details

Brand Name

IDEAL®

Alternate Supplier #

Grainger - 21GR21

Description

WEATHERPROOF® wire connectors are the perfect twist-on solution for connections that require protection from the elements. The swept wing design makes the connector easy and comfortable to apply, while the pre-filled, silicone based sealant protects against moisture and corrosion, eliminating the need for heat shrink or excessive taping.

IDEAL® WEATHERPROOF® Wire Connector, Series: 61® Series, Swept Wing/Twist-On Shell Style, Live Action/Square Wire Spring, Solid/Stranded Copper Wire, 22 to 14 AWG Wire, 600 VAC, Specifications: 3/8 in Wire Strip, (2) 20 AWG Minimum, (2) 14 AWG Maximum Conductor Combination Size, 105 deg C, Thermoplastic Polyester, Gray, 0.49 in Dia x 0.65625 in W x 0.90625 in H Dimensions

Application

Automatic Carwashes, Basement, Bathroom or Spa Vent Fans, Car Port Circuits, Garage, Decorative Patio and Deck Lighting, Exterior Area, Security Lighting, Industrial Hosedown or Washdown, Marine Shore Power and Dock Lighting, Outdoor Power Outlets, Outdoor Signage and Traffic Signal Control Circuits Applications

Standards

Features

100% silicone based sealant protects against moisture and corrosion
UL listed to 486D for use in damp/wet locations or above grade applications
Easy to apply, pre-filled twist-on wire connectors
Swept wing design is built for comfort and efficiency
Eliminates the need for heat shrink or excessive taping

Specifications

Color:	Gray
Country of Origin:	US
Dimensions:	0.49 in Dia x 0.65625 in W x 0.90625 in H
Material:	Thermoplastic Polyester
Series:	61® Series
Shell Style:	Swept Wing/Twist-On
Specifications:	3/8 in Wire Strip, (2) 20 AWG Minimum, (2) 14 AWG Maximum Conductor Combination Size
Spring Type:	Live Action/Square Wire
Temperature Rating:	105 deg C
Voltage Rating:	600 VAC
Wire Size:	22 to 14 AWG
Wire Type:	Solid/Stranded Copper
