30CIF06 BSF

Name: 30CIF06 BSF
Brand: Bussmann
SKU: 30CIF06 BSF
Availability: OutOfStock

Bussmann 30CIF06 Canadian HRC Fuse, 30 A

Manufacturer: Bussmann

Manufacturer part number: 30CIF06

Availability: Expected Leadtime 28 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

Price on Request

Qty:

Product Details

Brand Name

Bussmann

Type

Canadian

Description

Eaton's Bussmann British standard fuses can be used in multiple applications; industrial, utility, street lighting and domestic. Full range of rated current, voltage available as well as compatible fuse holders. They meet the BS88 part 1 and 2 and IEC 60269-1 and -2 standards.

Bussmann HRC Fuse, Canadian, 30 A

Application

For use in circuits subject to surge currents such as those caused by motors, transformers and other inductive loads

Standards

CE Certified | CSA C22.2 No. 106-M92

Features

Close sizing to loads allows using smaller and less costly switches
Provides a higher degree of short circuit protection
Helps protect motors against burnout from overloads
CIF06 fits the 30 A SafeLOC fuse holder

Specifications

Amperage Rating:	30 A
Body Size:	0.54 in Dia x 2.38 in L
Body Type:	Cartridge
Country of Origin:	GB
Interrupt Rating:	200 kA
Material:	Ceramic
Mounting Type:	Clip-In
Series:	CIF06
Terminal Type:	Offset Knife Blade
Voltage Rating:	600 VAC/250 VDC
