35D33R BSF

Bussmann 35D33R Low Voltage Non-Indicating Ultra Rapid D Fuse Link, 500 V, 35 A, For Use With Class gR Fuse, Ceramic
Manufacturer: Bussmann
Manufacturer part number: 35D33R
Availability: Expected Leadtime 71 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...
Price on Request

Product Details

Brand Name

Bussmann

Type

Low Voltage Non-Indicating Ultra Rapid

Description

Eaton's Bussmann series low voltage D and D0 bottle fuses are specifically designed for the protection of general industrial applications such as power distribution and cable protection. Both D and D0 fuse types are available in three operating characteristics: time delay, fast acting and ultra rapid versions that can fit into screw cap fuse carriers for mounting on 1 or 3 pole DIN-Rail or panel mount
Bussmann D Fuse Link, Low Voltage Non-Indicating Ultra Rapid, Series: D33, 500 V, 35 A, For Use With: Class gR Fuse, Ceramic, Black

Application

Aftermarket, Control Panels for Machines, Panel Builders, OEMs, Electrical Assemblies, Panels, For the protection of general industrial applications such as power distribution and control and cable protection, stationary machine equipment in factory - robotics

Standards

CE Certified | DIN 49515 | GOST-R Certified | IEC 60269 | VDE Approved

Features

  • Characteristics to suit the protection needs of inductive and resistive loads
  • Fast trouble shooting with easily visible fuse operated pin indicator
  • Historically reliable range
  • Fit into screw cap fuse link carriers for mounting in 1/3-pole DIN rail or screw fixing

Specifications

Amperage Rating:35 A
Color:Black
Country of Origin:SI
Dimensions:27 mm Dia x 50 mm L
Material:Ceramic
Mounting Type:Holder
Rated Breaking Capacity:50 kA
Series:D33
Suitable For Use With:Class gR Fuse
Voltage Rating:500 V
