Actual Product May Vary From Image

400NHG3B-690 BSF

Name: 400NHG3B-690 BSF
Brand: Bussmann
SKU: 400NHG3B-690 BSF
Availability: OutOfStock

Bussmann 400NHG3B-690 Dual Indicator Low Voltage Size 03 NH Fuse Link With Metal Live Gripping Lugs, 690 VAC, 400 A, For Use With NH Series Class C/gG/gL Fuse, Ceramic

Manufacturer: Bussmann

Manufacturer part number: 400NHG3B-690

Availability: Expected Leadtime 31 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON
0
Loading...

Price on Request

Qty:

Product Details

Brand Name

Bussmann

Type

Dual Indicator Low Voltage Size 03

Description

Eaton's Bussmann series low voltage NH fuses range from 2 amps to 1250 amps and provide world class leading performance and reliability. The range is fully compliant with IEC 60269-1, 60269-2, VDE 0636-2 third party approval and DIN 43620. Incorporating a dual indicator design (front and top) NH fuses are able to give both local visual indication and remote (via microswitch) fuse status. Eaton's Bussmann series NH fuses are available in the following operating classes gg, gff and am.

Bussmann NH Fuse Link, Dual Indicator Low Voltage Size 03 Lead Free, Series: NH Series, 690 VAC, 400 A, 45 to 62 Hz, Rated Breaking Capacity: 120 kAIC, Holder Mount, For Use With: NH Series Class C/gG/gL Fuse, Ceramic, 150 mm L x 75 mm W x 76 mm H

Application

Electrical Assemblies, Panels, EOEMs, Control Panels for Machines, Panel Builders, Industrial Facilities and Factories, Power Distribution and Control, Safety and Security Systems

Standards

CE Certified | CCC Certified | DIN 43620 | IEC 60269 | RoHS Compliant | UL Listed | VDE 0636

Features

Voltage conducting metal live gripping lugs
Reliable dual indicator system
Low temperature rise
Globally compliant
Steatite insulator, corrosion resistant aluminum end plates and plated steel screws, full contact silver plated brass blade construction
Cadmium and lead free
Low wattage loss
120 kA at 600 VAC interrupt rating

Specifications

Amperage Rating:	400 A
Dimensions:	150 mm L x 75 mm W x 76 mm H
Frequency Rating:	45 to 62 Hz
Material:	Ceramic
Mounting Type:	Holder
Rated Breaking Capacity:	120 kAIC
Series:	NH Series
Suitable For Use With:	NH Series Class C/gG/gL Fuse
Voltage Rating:	690 VAC
