Actual Product May Vary From Image

403000A10M040 WOO

Name: 403000A10M040 WOO
Brand: Molex/Woodhead
SKU: 403000A10M040 WOO
Price: 24.87 USD
Availability: OutOfStock

Brad® Nano-Change® Woodhead® 403000A10M040 120086 Single Ended Cordset, M8 Straight Female x Pigtail Connector, 4 m L Cable, 3 Poles, A-Coded Keyway

Manufacturer: Molex/Woodhead

Manufacturer part number: 403000A10M040

Availability: Expected Leadtime 7 days

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$24.87

Qty:

Product Details

Brand Name

Brad®

Type

Single Ended

Description

Nano-Change® (M8) industry standard connectors are rugged, space-saving, sealed connectors for miniature sensors and actuators in industrial control applications. Nano-Change® connectors are design to withstand harsh-industrial and weather environments. These connectors are used to interconnect miniature sensors and actuators found in industrial control applications.

Brad® Nano-Change® Woodhead® Cordset, Single Ended, Series: 120086, Straight Female x Pigtail Connector, M8 Connector, TPE Connector, 24 AWG Cable, 4 m Cable Length, PVC Cable, 3 Pole, A-Coded Keyway, 60 VAC, 3 A, Brown/Blue/Black Wire Pin

Application

For class 2 control, power and network circuits

Standards

CSA File No. LR6837 | UL File No. E152210 | UL 2661

Features

Gold plating mating, copper alloy contact material, TPE body material, nickel plated brass coupling nut
General M8 design meets IEC specifications industry standard interface compatible with a wide array of miniature sensors and actuators
Industry standard interface compatible with a wide array of miniature sensors and actuators
Waterproof design to withstand harsh-industrial environments
Prevents back-out in high vibration applications

Specifications

Amperage Rating:	3 A
Cable Length:	4 m
Cable Material:	PVC
Cable Type:	24 AWG
Connector Material:	TPE
Connector Size:	M8
Connector Type:	Straight Female x Pigtail
Country of Origin:	MX
Keyway:	A-Coded
Number of Poles:	3
Series:	120086
Voltage Rating:	60 VAC
Wire Pin Colors:	Brown/Blue/Black
