INA 4120 Axial Deep Groove Ball Bearing, 3.937 in Dia Bore, 5.906 in OD, 1.614 in W, 31000 lb Dynamic/8000 lb Static Load

Manufacturer: INA

Manufacturer part number: 4120

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

INA

Description

INA Axial Deep Groove Ball Bearing, Series: 41 Series, 3.937 in Bore Dia, 5.906 in Outside Dia, 1.614 in Width, Separable Face, Single Thrust Direction, 31000 lb Dynamic/8000 lb Static, 1600 rpm Maximum

Features

Medium cross section
Grooved race
Angular adjustment facility
Separable axial contact
Static alignment is equal to +/- 3.0 deg
Speed limit shown is for oil lubrication

Specifications

Bore Diameter:	3.937 in
Face Type:	Separable
Load Capacity:	31000 lb Dynamic/8000 lb Static
Maximum Speed:	1600 rpm
Outside Diameter:	5.906 in
Series:	41 Series
Thrust Direction:	Single
Width:	1.614 in
