Actual Product May Vary From Image

480-8MGT-20 GAT

Name: 480-8MGT-20 GAT
Brand: Gates
SKU: 480-8MGT-20 GAT
Price: 36.91 USD
Availability: OutOfStock

PowerGrip™ GT4

Manufacturer: Gates

Manufacturer part number: 480-8MGT-20

Availability: Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$36.91

Qty:

Product Details

Brand Name

Gates

Alternate Supplier #

95799001

Description

Engineered with the latest in advanced technology and materials science expertise, Gates PowerGrip™ GT4 delivers the highest power-carrying capacity of any belt in its class. In addition, Gates designed a belt with increased chemical resistance and larger temperature range capability. Gates PowerGrip GT4 belt delivers improved performance over a wide range of industrial applications. The 8MGT and 14MGT pitches are the optimum choice for high performance drives in the machine tool, paper and textile industries where durability and low maintenance are required. From resource processing to heavy manufacturing, automated production to custom assembly — Gates PowerGrip GT4 solutions improve uptime, efficiency, productivity, reliability and safety for industries around the world.

Features

Next-generation Ethylene Elastomer body provides class-leading power capacity and temperature range. Fiberglass tensile cord provides high strength, excellent flex life and high resistance to elongation. Nylon tooth facing provides a durable wear surface for long service life. Static-conductive (ISO 9563) and for conditions described in the Directive 2014/34/EU-ATEX. Higher power-carrying capacity giving you the option to use a narrower belt. No lubrication and less re-tensioning eliminates maintenance costs throughout the life of the belt.

Specifications

Belt Back Side:	Smooth
Belt Height (in):	0.22
Belt Height (mm):	5.59
Belt/Slab:	Belt
Color:	Black
Cord Material:	Fiberglass
Country of Origin:	US
End:	Endless
Fabric Material:	Nylon Teeth
GC Base Product:	Powergrip™ GT4™ Rubber Synchronous Belt - 8mm Pitch
Harmonized Tariff Code:	4010.39.4500
Length Pitch (in):	18.9
Length Pitch (mm):	480
Material:	Ethylene Elastomeric
Max Temp (°C):	+120
Max Temp (°F):	+248
Min Temp (°C):	-40
Min Temp (°F):	-40
Number of Teeth:	60
Pitch (in):	0.315
Pitch (mm):	8
Proposition 65:	NO
Section:	8M
Sided:	Single Sided
Sprock Comptab:	PowerGrip GT
Standard Width:	YES
Stat Conductive:	Yes
Tooth Form:	GT Design
Tooth Height (in):	0.129
Tooth Height (mm):	3.28
Width (in):	0.787
Width (mm):	20
