Actual Product May Vary From Image

50C20 MSG

Name: 50C20 MSG
Brand: Martin Sprocket & Gear
SKU: 50C20 MSG
Price: 111.85 USD
Availability: OutOfStock

Martin 50C20 Type C Single Strand Welded Reboreable Roller Chain Sprocket, 3/4 to 2 in Dia Bore, 4.321 in OD, #50 Chain, 20 Teeth, 5/8 in Pitch, Steel

Manufacturer: Martin Sprocket & Gear

Manufacturer part number: 50C20

Availability: Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

$111.85

Qty:

Product Details

Brand Name

Martin

Type

Type C Single Strand Welded Reboreable

Description

C Style sprockets are flat sprockets with a hub extension on either side. These plain bore sprockets can easily be bored to a metric or standard size to fit your application. Keyways, setscrews and hardened teeth are quick alterations that can be made.

Martin Roller Chain Sprocket, Type C Single Strand Welded Reboreable, 3/4 to 2 in Bore, 4.321 in OD, #50 Chain, 20 Teeth, 5/8 in Pitch, 3.9953 in Pitch Diameter, 3.313 in Diameter Hub, 1-5/8 in Length Through Bore, Steel

Standards

ANSI Specified | B29.1 - 1975

Features

Precise machining and processes ensure consistent finish and high quality
Bores are concentric to pitch line, minimizing run out
Manufactured of high carbon steel

Specifications

Bore Diameter:	3/4 to 2 in
Chain Size:	#50
Hub Diameter:	3.313 in
Length Through Bore:	1-5/8 in
Material:	Steel
Number of Teeth:	20
Outside Diameter:	4.321 in
Pitch:	5/8 in
Pitch Diameter:	3.9953 in
