5102-DFS3-DFM PRS

Name: 5102-DFS3-DFM PRS
Brand: Prosoft Technology
SKU: 5102-DFS3-DFM PRS
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Prosoft Technology

Manufacturer part number:

5102-DFS3-DFM

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

PROSOFT

Type

Stand-alone Gateway

Description

The DF1 Serial Port Expander Gateway allows you to attach up to three separate DF1 master devices to a single DF1 slave. The module is designed to act as a multiplexer, allowing simultaneous connections from multiple DF1 masters to a single DF1 slave. A c

Application

Manufacturing, Oil and Gas, Electrical Power and Food Processing.

Standards

ATEX, CE/EMC, Environmental, UL,GOST-R

Features

Adds three additional slave ports for a DF1 based device; Allows users to connect programming software, HMI, and modems to processors simultaneously; Commands from the host devices are passed through the module and routed directly to the front port of the processor.

Specifications

Configuration:	Yes
Connectivity:	Serial
Country of Origin:	USA
Data Transfer Rate:	110 to 115 KBPS
Enclosure:	Aluminum
Environmental Conditions:	-20 to 50DEG C Operating, -40 to 85DEG C Storage, 5 to 95 Percent Humidity
Ethernet:	10Base-T
Frequency Rating:	50 to 60 HZ
Height:	5.2 IN
Interface:	RS-232, RS-422, RS-485
Length:	4.52 IN
Port:	4
Protocol:	DF1
Software Requirements:	Drivers
Sub Brand:	5000
Width:	2.07 IN
