51120 INA

Name: 51120 INA
Brand: INA
SKU: 51120 INA
Availability: OutOfStock

FAG 51120 Axial Deep Groove Ball Bearing, 100 mm Dia Bore, 135 mm OD, 1 Rows, 25 mm W, 85000 N Dynamic/270000 N Static Load

Manufacturer: INA

Manufacturer part number: 51120

Availability: Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

CBT - Cincinnati	CBT - Springboro	CBT - Sidney
0	0	0
CRUSH BEARINGS & DRIVES - LEXINGTON	CRUSH BEARINGS & DRIVES - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

FAG

Description

FAG Axial Deep Groove Ball Bearing, Series: 511 Series, 100 mm Bore Dia, 135 mm Outside Dia, 1 Rows, 25 mm Width, Separable Face, Single Thrust Direction, 85000 N Dynamic/270000 N Static, Steel Bearing, 3500 rpm Maximum, -30 to 150 deg C

Standards

Meets to DIN 711/ISO 104

Features

Sheet steel cage

Specifications

Bearing Material:	Steel
Bore Diameter:	100 mm
Face Type:	Separable
Load Capacity:	85000 N Dynamic/270000 N Static
Maximum Speed:	3500 rpm
Number of Rows:	1
Outside Diameter:	135 mm
Series:	511 Series
Temperature Rating:	-30 to 150 deg C
Thrust Direction:	Single
Width:	25 mm
