5252AW HWD

Wiring Device-Kellems Hubbell-Pro™ 5252AW 1-Phase Duplex Grounding Heavy Duty Standard Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, White
Manufacturer part number: 5252AW
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$2.50

Product Details

Brand Name

Wiring Device-Kellems

Type

1-Phase Duplex Grounding Heavy Duty Standard

Alternate Supplier #

Grainger - 6C636

Description

Wiring Device-Kellems Hubbell-Pro™ Straight Blade Receptacle, 1-Phase Duplex Grounding Heavy Duty Standard, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial/Industrial Grade, -40 to 75 deg C, Back/Side Wire Terminal, Composite/Thermoplastic, White, 3.28 in H x 1.406 in W x 1.094 in D Dimensions

Application

Indoor Dry Environment

Standards

RoHS Compliant | UL 498 File No. E2186 | CSA C22.2 No. 42/285 | NEMA WD1/WD5 | UL94 V-2 Flammability Rating

Features

  • Withstands 2000 VAC dielectric voltage
  • Certified for current interrupting at full rated current
  • Slender compact design
  • Smooth face
  • Triple wipe contacts
  • 14 to 10 AWG copper stranded or solid conductor only terminal accommodation
  • Terminal wire leads identified in accordance with UL 498
  • Nylon top and base, PBT base, brass contacts, galvanized steel mounting strap, stainless steel automatic self-grounding staple, zinc plated steel mounting screws
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%
  • Traditional face shape

Specifications

Amperage Rating:15 A
Color:White
Country of Origin:CN
Dimensions:1.406 in W x 1.094 in D x 3.281 in H
Grade:Commercial/Industrial
Horsepower:1/2 hp
Material:Composite/Thermoplastic
NEMA Rating:5-15R
Number of Poles:2
Number of Wires:3
Temperature Rating:-40 to 75 deg C
Terminal Type:Back/Side Wire
Voltage Rating:125 VAC
