Picture of 5262I HWD
Actual Product May Vary From Image

5262I HWD

Wiring Device-Kellems Hubbell-PRO™ 5262I 1-Phase Duplex Grounding Heavy Duty Standard Traditional Screw Mount Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Ivory
Manufacturer: Hubbell Wiring Device-Kellems
Manufacturer part number: 5262I
Availability: Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$4.92

Product Details

Brand Name

Wiring Device-Kellems

Type

1-Phase Duplex Grounding Heavy Duty Standard Traditional Screw Mount

Alternate Supplier #

Grainger - 2WMP9

Description

Wiring Device-Kellems Hubbell-PRO™ Straight Blade Receptacle, 1-Phase Duplex Grounding Heavy Duty Standard Traditional Screw Mount, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, 5-15R NEMA Rating, Industrial/Specification Grade, -40 to 75 deg C, Side Wired Terminal, Thermoplastic/Composite, Ivory, 1.41 in W x 1.09 in D x 3.28 in H

Application

Indoor Dry Environment

Standards

RoHS Compliant | CSA File No. 285 | NEMA WD1/WD5 WD6 | UL 498 File No. E2186

Features

  • Back and side wiring method
  • 0.031 in brass contact
  • 0.04 in galvanized steel mounting strap
  • Stainless steel auto ground clip
  • Steel zinc plated mounting screw
  • Withstands 2000 VAC minimum dielectric voltage
  • Certified for current interrupting at full rated current
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% rated current for either AC or DC applications per UL 498 temperature rise
  • Terminals identified in accordance with UL 498
  • 14 to 12 AWG wire size

Specifications

Amperage Rating:15 A
Color:Ivory
Country of Origin:US
Dimensions:1.41 in W x 1.09 in D x 3.28 in H
Grade:Commercial/Industrial
Horsepower:1/2 hp
Material:Composite/Thermoplastic
NEMA Rating:5-15R
Number of Poles:2
Number of Wires:3
Temperature Rating:-40 to 75 deg C
Terminal Type:Back/Side Wire
Voltage Rating:125 VAC
