5B101-H01 LEV

Name: 5B101-H01 LEV
Brand: Leviton Manufacturing
SKU: 5B101-H01 LEV
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Leviton Manufacturing

Manufacturer part number:

5B101-H01

CBT Inventory

Vendor Inventory

Availability:

Ships in 5-7 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Leviton®

Type

1-Phase 2-Wire

Description

The VerifEye™ potted Mini Meter™ line of revenue grade meters come with permanently attached, highly accurate solid core current transformers (CTs) for revenue grade performance certified to ANSI standards.

Leviton® VerifEye™ Potted Mini Meter, 1-Phase 2-Wire, 120 VAC, 100 A, LCD/Mechanical Counter Display, Isolated Pulse Output Communication, -22 to 140 deg F Operating, Epoxy, 5.9 in H x 8.47 in W x 3.57 in D

Application

Load Profiling and Benchmarking, Usage Aggregation, Tenant Cost Allocation, Measurement and Verification, Energy Conservation and Cost Reduction, Green Building Initiatives and Government Mandates Applications

Standards

ANSI C12.1 | ASHRAE 90.1 | Title 24 Compliant

Features

Measures kWh meter
Equipped standard with an isolated pulse output channel for automated meter reading
Utilizes revenue grade 0.3% accuracy class 0.1 A secondary solid core current transformers (CTs) that conform to all applicable ANSI requirements

Includes

Solid Core Current Transformer

Specifications

Amperage Rating:	100 A
Communication:	Isolated Pulse Output
Country of Origin:	US
Dimensions:	5.9 in H x 8.47 in W x 3.57 in D
Display Type:	LCD/Mechanical Counter
Material:	Epoxy
Operating Temperature:	-22 to 140 deg F
Voltage Rating:	120 VAC
