6016 C3 RLW

Deep groove ball bearings are non-separable, comparatively rigid radial bearings. their balls are guided in deep radial running grooves. They are characterized by a high radial and axial load carrying capacity and can operate at very high speed. Combined loads are accommodated to an optimum degree. In fact, at higher speeds they are often better suited to transmit thrust loads than the ball thrust bearing. For these reasons and also economical price, it is the most widely used bearing.

Rollway® Deep Groove Ball Bearing, Round Straight Bore Unmounted, Series: 6000, 80 mm Bore Dia, 125 mm Outside Dia, 1 Row, 22 mm W, Open Closure, 47.6 kN Dynamic/39.8 kN Static, 52100 Steel Bearing, Pressed Steel Cage, 5300 rpm Grease/6300 rpm Oil Maximum, -30 to 120 deg C
