6AS10-3E LEV

Product Details

Manufacturer part number:
6AS10-3E
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 5-7 days.
Estimated dates are contingent upon manufacturer stock.

Description

Brand Name

Leviton®

Type

FTP SlimLine Boot

Description

Atlas-X1™ Cat 6A SlimLine Boot Patch Cords exceed all channel performance requirements in ANSI/TIA-568-C.2 from 1 MHz to 500 MHz to support the IEEE 802.an standard for 10 Gigabit Ethernet over UTP Cable. The patch cords provide superior alien crosstalk suppression and protect critical data from EMI (electromagnetic interference) and RFI (radio frequency interference). They are ideal for use in a UTP Cat 6A system, or as part of a Cat 6A shielded system for use in healthcare, manufacturing, casinos, and other environments where alien crosstalk may be a concern. The shielded technology is Rockwell Automation Encompass™ approved.
eXtreme® Atlas-X1™ Patch Cord, SlimLine Boot, Series: 6AS10, Category: Cat 6a, 26 AWG Conductor, FTP Stranded Conductor, 3 ft Cord Length, Black Jacket

Application

Data Center, Telecommunication Rooms, Healthcare, Manufacturing and Casino Applications

Standards

ANSI/TIA-568-C.2 | ISO/IEC 11801 Cat 6A | cULus Listed | ANSI/TIA-1096-A | UL 444 | IEEE 802.3at (Type 1)/802.3at (Type 2)/Draft 802.3bt/D1.2 (Type 3)/IEEE Draft 802.3bt/D1.2 (Type 4)

Features

  • Independently tested and verified by Intertek (ETL) for Cat 6A component performance
  • Cable construction provides excellent alien crosstalk suppression and EMI/RFI protection
  • SlimLine plug/boot features a narrow profile for less congestion in higher density applications
  • Snagless design prevents tab breakage
  • Strain relief boot ensures long term network performance
  • Outside diameter of 0.24 in easier to manage
  • 26 ga stranded conductors for maximum flexibility
  • Same cord for UTP or shielded installations
  • Manufactured by Leviton® using Berk-Tek cable

Specifications

Category Type:CAT 6a
Color:Black
Conductor Size:26 AWG
Conductor Type:FTP Stranded
Connector Type:Plug
Cord Length:3 ft
Country of Origin:US
Jacket Color:Black
Series:6AS10
