6TFS14 MSG

Martin 6TFS14 U-Trough Feeder Shroud, 0.0747 in THK Shroud, 4-1/2 in Drop to Screw Centerline, Steel
Manufacturer: Martin Sprocket & Gear
Manufacturer part number: 6TFS14
Availability: Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
Price on Request

Product Details

Brand Name

Martin

Description

Shrouds are used in trough sections of screw feeders to decrease the clearance between the cover and feeder screw to obtain proper feed regulation. Lengths are sufficient to prevent flushing of the majority of materials being handled and gauges are proportioned to trough size and gauge.
Martin U-Trough Feeder Shroud, 0.0747 in THK Shroud, 4-1/2 in Drop to Screw Centerline, Steel, 12 in L x 7 in W x 2-13/16 in H

Application

Used in trough sections of screw feeders

Standards

CEMA/NIBA Standards

Features

Laser cut flat pieces to ensure consistent finish dimensions

Specifications

Dimensions:12 in L x 7 in W x 2-13/16 in H
Material:Steel
Specifications:0.0747 in THK Shroud, 4-1/2 in Drop to Screw Centerline
