7204B BLT

Single Row Angular Contact Ball Bearings are used in applications that call for thrust or combination thrust and radial loads. Standard production is made with a 40 deg contact angle (B suffix but can also be produced with a 25 deg contact angle (A suffix) or 15 deg angle (C suffix). Retainers are constructed of steel (B/BG) or brass (B/BMG). Non-metallic cages can be made upon request.

TRITAN® Angular Contact Ball Bearing, Light Duty, Series: 7200 Series, 20 mm Bore, 47 mm OD, 1 Rows, 14 mm Width, 40 deg Contact Angle, 3170 lb Load, 52100 Chromium Steel Bearing, Polyamide Cage, 11000 rpm Grease/16000 rpm Oil Maximum
