7214WN TKN

Name: 7214WN TKN
Brand: Timken
SKU: 7214WN TKN
Price: 579.73 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Timken

Manufacturer part number:

7214WN

CBT Inventory

Vendor Inventory

Availability:

Ships in 3-5 days.

Estimated dates are contingent upon manufacturer stock.

$579.73 / EA

Description

Brand Name

Fafnir®

Type

Light Duty Straight Bore

Description

Timken® Angular Contact Ball Bearings are designed to handle high speeds with both radial and axial loads with reliable performance in pump, compressor, electric motor and many other industrial applications. Our products offering includes a range of single-row universally matched, single-row standard and double-row products with different cage types, contact angles and tolerances.

Timken® Fafnir®, 7214WN, Angular Contact Ball Bearing, Light Duty Straight Bore, Series: 7200, 70 mm Bore, 125 mm OD, 1 Rows, 24 mm Width, 40 deg Contact Angle, Open Closure, 15500 lb Dynamic/12900 lb Static Load, Steel Bearing, Pressed Brass Cage, 78153.49 rpm Grease/104204.65 rpm Oil Maximum, -50 to 120 deg C

Application

Aircraft, Construction, Agricultural, Machine Tool and General Industry Applications

Standards

Precision Class ABEC 1

Features

Enhanced raceway finish
Quiet operation
Dimensionally interchangeable

Specifications

Bearing Material:	Steel
Bore Diameter:	70 mm
Cage Material:	Pressed Brass
Closure Type:	Open
Contact Angle:	40 deg
Load Capacity:	15500 lb Dynamic/12900 lb Static
Maximum Speed:	78153.49 rpm Grease/104204.65 rpm Oil
Number of Rows:	1
Outside Diameter:	125 mm
Series:	7200
Temperature Rating:	-50 to 120 deg C
Width:	24 mm
