75120-7M3 LEV

Name: 75120-7M3 LEV
Brand: Leviton
SKU: 75120-7M3 LEV
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Leviton

Manufacturer part number:

75120-7M3

CBT Inventory

Vendor Inventory

Availability:

Ships in 5-7 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Leviton®

Type

Type 2

Description

Leviton surge protection devices can be used individually or as part of a coordinated application strategy, to protect sensitive electronic equipment, in industrial, commercial and residential locations, from the stress and degradation inflicted by voltage transients. Leviton® surge protection devices are compliant with UL 1449 Standards. Leviton outstanding surge protection devices divert damaging voltage transients, or surges, away from electronic equipment. Transients are diverted away from sensitive micro circuitry, providing protection against catastrophic failure, costly downtime and data disruptions.

Leviton® Surge Protective Device, Type 2, 120/208 VAC, 50/60 Hz, 3, 10 kA Short Circuit, LED/Noise Filtering/Surge Counter Indicator, Environmental Conditions: -20 to 85 deg C Storage, 5 to 95% Non-Condensing Humidity, UL94 V-2 Flammability, NEMA 12, 15.8 in H x 19.71 in W x 8.33 in D, Powder Coated Steel

Application

Commercial Applications

Standards

CSA Certified | ANSI | IEEE C-62.41/C-62.45 | cULus 1449

Features

30 A at 120 VAC recommended circuit breaker
53mm MOV surge technology
Maximum surge current, per mode (per phase): 320 kA (640 kA)
(7) HC120-M53 module
Voltage protection rating VPR clamping L-L, L-N, L-G, N-G: 1500, 800, 800, 600
5% to 95% non-condensing relative humidity
MCOV: 150 VAC
-20 to 85 deg storage temperature
7-mode protection
Connection type: Parallel hardwire using terminal block
300 V Maximum voltage
Operating temperature: -10 to 60 deg C
10 kA short circuit current
120/208 VAC 3-phase WYE voltage configuration
UL1449 Impulse 6 kV/500 A L-N/L-G/N-G/L-L, 400/400/400
Noise Filtering: -40 dB at 5 kHz to 100 MHz
10 kA nominal discharge current rating
Remote monitoring: dry contact leads NO/NC form C rated at 7 A at 240 VAC or 30 VAC
10 year warranty

Specifications

Country of Origin:	MX
Dimensions:	15.8 in H x 19.71 in W x 8.33 in D
Electrical Ratings:	120/208 VAC
Enclosure Type:	NEMA 12
Environmental Conditions:	-20 to 85 deg C Storage, 5 to 95% Non-Condensing Humidity, UL94 V-2 Flammability
Frequency Rating:	50/60 Hz
Indicator Type:	LED/Noise Filtering/Surge Counter
Material:	Powder Coated Steel
Phase:	3
Short Circuit Current Rating:	10 kA
