7599-HGE LEV

Product Details

Manufacturer part number:
7599-HGE
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 5-7 days.
Estimated dates are contingent upon manufacturer stock.
Price on Request

Description

Brand Name

Leviton®

Type

Duplex

Description

Leviton is the leading manufacturer of Ground Fault Circuit Interrupters (GFCIs) in the electrical industry. Available in Extra Heavy Duty Hospital and Commercial Spec Grade, they are ideal for a wide range of GFCI applications. Our large selection of GFCIs includes Tamper-Resistant (TR) GFCI devices that meet Section 406.11 of the 2008 code and help protect children from electrical shock. For the highest level of ground fault protection, install 2008 NEC code compliant Weather-Resistant GFCI (WR) receptacles, which meet UL 498 requirements. Built with UV stabilized engineering thermoplastic, the devices have high cold impact resistance and feature stainless steel straps and mounting screws.
SmartlockPro® GFCI Receptacle, Duplex, 125 VAC, 15 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial/Hospital Grade, -35 to 66 deg C, Back/Side Wire Terminal, Polycarbonate, Black, 4.21 in H x 1.31 in W x 1.19 in D Dimensions

Application

Commercial Applications

Standards

ANSI C73 | NOM 057 Certified | CSA C22.2 No. 42 | CSA File No. LR-57811 | UL 498HG | UL File No. E13399/E48380 | UL 943

Includes

Nylon Wallplate and Screws

Specifications

Amperage Rating:15 A
Color:Black
Country of Origin:CN
Dimensions:4.21 in H x 1.31 in W x 1.19 in D
Grade:Commercial/Hospital
Horsepower:1 hp
Material:Polycarbonate
NEMA Rating:NEMA 5-15R
Number of Poles:2
Number of Wires:3
Temperature Rating:-35 to 66 deg C
Terminal Type:Back/Side Wire
Voltage Rating:125 VAC
