75EET BSF

Name: 75EET BSF
Brand: Bussmann
SKU: 75EET BSF
Price: 481.51 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Bussmann

Manufacturer part number:

75EET

CBT Inventory

Vendor Inventory

Availability:

Expected Leadtime 31 days

Estimated dates are contingent upon manufacturer stock.

$481.51 / EA

Description

Brand Name

Bussmann

Type

Type EET British Style BS88 Semi-Conductor

Description

Eaton's Bussmann British standard BS88 fuses can be used in multiple applications; industrial, utility, street lighting and domestic. Full range of rated current and voltage available as well as compatible fuse holders. They meet the BS88 part 1 and 2 and IEC 60269-1 and -2 standards.

Bussmann High Speed Fuse, Type EET British Style BS88 Semi-Conductor, Indicating/Non-Indicating: Non-Indicating, 75 A, 690 V, 50/200 kA Interrupt, Class: AR, Blade Terminal, Stud Mount, Cartridge Body Type, 94 mm L x 37 mm W x 19 mm H Body Size

Application

Aftermarket, Control Panels for Machines, Panel Builders, OEMs, Electrical Assemblies, Panels, For power distribution and control, DC common bus, DC drives, power converters/rectifiers and reduced voltage starters, safety and security systems

Standards

CCC Certified | CE Certified | IEC 60269 | RoHS Compliant | UL Recognized

Features

Low arc voltage and low energy let through
Excellent cycling capability and DC performance
Excellent DC performance
BS88 style bolted tags high speed fuses

Specifications

Amperage Rating:	75 A
Body Size:	94 mm L x 37 mm W x 19 mm H
Body Type:	Cartridge
Class:	AR
Country of Origin:	IN
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	200 kA
Mounting Type:	Stud
Terminal Type:	Blade
Voltage Rating:	690 V
