Home / 7765N WOO

7765N WOO

Picture of 7765N WOO
Actual Product May Vary From Image

Product Details

Manufacturer:
Molex (Woodhead)
Manufacturer part number:
7765N
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Expected Leadtime 12 days
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$166.49 / EA

Description

Brand Name

Woodhead®

Type

Male

Description

Woodhead® Super-Safeway products are heavy duty industrial-wiring devices designed for abusive conditions and dependable performance for applications that demand the unmatched durability that rubber exclusively delivers. These rubberized industrial devices are the only wiring devices made of NEo-TEX® Paracril OZO rubber, a rubber construction that yields ultimate performance within a wide temperature range, around many oils and chemicals and abrasive conditions.
Woodhead® Safeway® Locking Plug, Male, Series: 130155, 600 VAC/250 VDC, 50 A, 3 Pole, 4 Wires, Industrial Grade, -40 to 75 deg C, Screw/Wire Terminal, Nylon, Yellow

Application

Aircraft Construction/Airports, Construction Site, Facility Maintenance, Petrochemical, Pulp and Paper Manufacturing Applications

Standards

CAS LR6837 | UL E10176

Features

  • Rugged nylon bodies within the Safeway® offering provide exceptional durability and performance
  • Color coded 1/4 in terminal screws pre set in open position, ready to wire
  • Wire screw terminals are tri-drive to be used with straight blade, Phillips® and square drive screw drivers
  • Floating blade construction provides self-alignment and a better mechanical and electrical connection minimizing wear and heat generation
  • Transparent wiring guide to verify all wire strands are in place before securing wire
  • Captive, tri-drive head, stainless steel, speed screw provides easy assembly and long life
  • Two piece cord clamp strain relief includes tri-drive screws to firmly secure the cord
  • Nickel plated brass plug blades and connector contacts
  • Nylon Safeway outer housing
  • Stainless steel face screw
  • Nylon face insert
  • Brass wire saddle clamp
  • zinc plated steel cord clamp screws
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75%
  • Non-NEMA configuration

Specifications

Amperage Rating:50 A
Color:Yellow
Country of Origin:MX
Grade:Industrial
Material:Nylon
Number of Poles:3
Number of Wires:4
Series:130155
Temperature Rating:-40 to 75 deg C
Terminal Type:Screw/Wire
Voltage Rating:600 VAC/250 VDC
