7ASDP OZG

Picture of 7ASDP OZG
Actual Product May Vary From Image

Product Details

Manufacturer:
Appleton
Manufacturer part number:
7ASDP
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 5-7 days.
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$3,304.72 / EA

Description

Brand Name

O-Z/Gedney

Type

Inertia Unidirectional

Description

O-Z/Gedney Pump Engine Switch, Inertia Unidirectional, Series: 7A Series, 125/250 VAC/VDC, Snap Switch, Domestic

Application

Oil Well Applications

Standards

Buy American Act Compliant | UL 698 | Class I, Division 1, 2, Group D | Class I, Zone 1, 2, Group IIA | Class II, Division 1, 2, Group E, F, G | Class III

Features

  • The inertia switch is a unidirectional shut down device that operates upon sharp impact and provides protection for oil well pumping unit
  • When installed properly, the switch will shut down the pump engine or motor upon impact occurring from sucker rod breakage
  • An external adjustment screw varies the impact trip level of the switch
  • The desired setting should prevent tripping on start up and normal operation, but trip upon malfunction
  • The switch should be located at a position subject to maximum shock forces
  • It should never be installed immediately adjacent to bearing surfaces

Specifications

Country of Origin:US
Domestic/Import:Domestic
Series:7A Series
Switch Type:Snap
Voltage Rating:125/250 VAC/VDC
