7E4PT.6 LIT

Name: 7E4PT.6 LIT
Brand: Littelfuse
SKU: 7E4PT.6 LIT
Price: 306.76 USD
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Littelfuse

Manufacturer part number:

7E4PT.6

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

$306.76 / EA

Description

Brand Name

Littelfuse®

Type

E-Rated Fast Acting Potential Transformer

Description

Potential transformer (PT) fuses are current limiting fuses with high interrupting ratings designed for the protection of potential transformers. Application note when applying fuses for the protection of transformers, the magnetizing current inrush must be considered. The characteristics of the inrush, which can be matched with a fuse's time current curve, should be available from the transformer manufacturer.

Littelfuse® POWR-GARD® Medium Voltage Fuse, E-Rated Fast Acting Potential Transformer, Indicating, 7 A, 0.6 kV, 37.5 kA Interrupt, Class: E, Holder Mounting, Cartridge Body, 0.8125 in Dia x 4.6 in L Body

Application

Transformers, Potential Transformers, Feeders and Motor Circuits, Electronic Equipment and Appliances

Standards

UL 248-14 | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer

Specifications

Amperage Rating:	7 A
Body Size:	0.8125 in Dia x 4.6 in L
Body Type:	Cartridge
Class:	E
Country of Origin:	MX
Indicating/Non-Indicating:	Indicating
Interrupt Rating:	37.5 kA
Mounting Type:	Holder
Voltage Rating:	0.6 kV
