803P801 WOO

Picture of 803P801 WOO
Actual Product May Vary From Image

Product Details

Manufacturer:
Molex (Woodhead)
Manufacturer part number:
803P801
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Expected Leadtime 7 days
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$718.18 / EA

Description

Brand Name

Brad®

Type

8-Port

Description

Micro-Change® (M12) connectors are designed to withstand harsh industrial and weather environments with superior quality that assures very reliable connections for control elements in automated equipment. These high quality connectors allow fast and simple replacement of sensors, encoders, switches and other input and output devices in industrial machinery.
Brad® Micro-Change® Molded Junction Box, 8-Port, Series: 120115, 10 to 30 VDC, 4 A, 5 Pole, 4 Wires, IP67 Enclosure, Side Mounting, 6 NEMA Rating, PBT

Application

Construction and Mining Equipment, Sensor, Machine Lighting, Standard Industrial Lighting, C4ISR, Ground Vehicle Network, Shelter, Automated Assembly Equipment, Conveyor System, Material Handling, Packaging Equipment and Pick and Place Robot

Standards

CE Marked

Features

  • M12 design meets IEC specifications
  • Ideal for class 2 power and network circuit applications
  • Provides a longer lasting, high performance electrical contact
  • Prevents the coupler from loosening even under extreme vibration
  • Robust housing provides superior electro magnetic interference (EMI) and radio frequency interference (RFI) protection
  • Watertight panel mount design
  • PNP functional wiring
  • Single input/output per port wiring configuration
  • PVC cable jacket, copper alloy metal, gold over nickel plating mating material
  • 4-pole wired
  • 5 m cable
  • With molded cable

Specifications

Amperage Rating:4 A
Country of Origin:MX
Enclosure Type:IP67
Material:PBT
Mounting Type:Side
NEMA Rating:6
Number of Poles:5
Number of Wires:4
Series:120115
Voltage Rating:10 to 30 VDC
