8505-0118F1 DIC

Name: 8505-0118F1 DIC
Brand: Dichtomatik
SKU: 8505-0118F1 DIC
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Dichtomatik

Manufacturer part number:

8505-0118F1

CBT Inventory

Vendor Inventory

Availability:

1-2 weeks.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

DICHTOMATIK

Description

DICHTOMATIK nitrile U-cups are designed to fit in most U-cup seal glands. They are manufactured in 70, 80 and 90 durometer nitrile depending on the profile. The profiles are rated for dynamic applications with a rod speed of 1.5 ft/sec (0.5 m/sec). The pressure ratings can be increased with the use of a back-up ring.

DICHTOMATIK U-Cup Seal, Series: 8500, 1.187 in ID, 1-1/2 in OD, 90 Durometer, 0.156 in Width, U-Shape Cross Section, 5 to 390 deg F, FKM, Import

Application

Use with pneumatic and low pressure hydraulic cylinders, piston and rod sealing

Features

Low friction performance in rod or piston applications assures easy movement without excessive drag
Easy assembly: Stretches or snaps into place resulting in lower assembly costs
FKM is one of the most highly temperature resistant of all commercially available elastomers
FKM is also great for oil resistance and chemical resistance

Specifications

Country of Origin:	TW
Cross Section Shape:	U-Shape
Domestic/Import:	Import
Durometer:	90
Inside Diameter:	1.187 in
Material:	FKM
Outside Diameter:	1-1/2 in
Series:	8500
Temperature Rating:	5 to 390 deg F
Width:	0.156 in
