884030B02M020 WOO

Brad® Micro-Change® 884030B02M020 120066 Double Ended Cordset, M12 Straight Female x Straight Male Connector, 6.56 ft L Cable, 4 Poles, Single Keyway
Manufacturer: Molex/Woodhead
Manufacturer part number: 884030B02M020
Availability: Expected Leadtime 7 days
Estimated dates are contingent upon manufacturer stock.
CBT - Cincinnati CBT - Springboro CBT - Sidney
0 0 0
CRUSH BEARINGS & DRIVES - LEXINGTON CRUSH BEARINGS & DRIVES - LOUISVILLE
0 0
Loading...
$60.17

Product Details

Brand Name

Brad®

Type

Double End

Description

Brad® Micro-Change® Cordset, Double Ended, Series: 120066, Straight Female x Straight Male Connector, M12 Connector, PUR, 6.56 ft Cable Length, PUR Cable, 4 Pole, Single Keyway, 250 VAC/VDC, 4 A

Application

Construction and Mining Equipment, Machine Lighting, Ground Vehicle Networks, Automated Assembly Equipment, Conveyor Systems and Material Handling

Standards

CSA LR6837 | UL E152210 | UL 20549 | RoHS Compliant

Features

  • M12 design meets IEC specifications
  • Ideal for class 2 power and network circuit applications
  • Provides a longer-lasting, high performance electrical contact
  • Prevents the coupler from loosening even under extreme vibration
  • Water-tight panel-mount design
  • 18 AWG yellow cable
  • Copper alloy contact, nickel plated brass coupling nut, fluoro-elastomer O-ring, Gold over nickel plating mating
  • 0.29 in cable diameter
  • -20 to 80 deg C operating temperature

Specifications

Amperage Rating:4 A
Cable Length:2 m
Cable Material:Polyurethane
Connector Material:Polyurethane
Connector Size:M12
Connector Type:Straight Female x Straight Male
Country of Origin:MX
IEC Rating:IEC 60664
Keyway:Single
NEMA Rating:NEMA IP67
Number of Poles:4
Series:120066
Voltage Rating:250 VAC/VDC
Wire Pin Colors:Black/Blue/Brown/White
