8RBA4-400E BSF

Picture of 8RBA4-400E BSF
Actual Product May Vary From Image

Product Details

Manufacturer:
Bussmann
Manufacturer part number:
8RBA4-400E
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
Availability:
Expected Leadtime 28 days
Estimated dates are contingent upon manufacturer stock.
Log in for more accurate pricing
$1,489.39 / EA

Description

Brand Name

Bussmann

Type

Type RBA4 Single Barrel Standard Speed

Description

Westinghouse electric company introduced the redesigned and improved RBA (indoor with exhaust control device filter or condenser) and RDB (vented outdoor dropout) ranges of boric acid DE-ION® fuses to replace the BA range of fuses EATON RBA (refillable boric acid) and RDB (refillable dropout boric acid) power fuses are expulsion type power fuses designed for indoor or weatherproof enclosure (RBA) or outdoor vented (RDB) applications. RBA/RDB fuses are renewable (refillable) as the descriptions above state. The whole fuse unit is not discarded after a fault interruption. Usually, only 1-piece of the fuse, the refill unit, needs to be replaced after an interruption and for this reason, RBA/RDB fuses provide an economical approach to the protection of power circuits rated up to a maximum of 38 kV. They are especially well suited for large industrial load fusing needs.
Bussmann Expulsion Fuse Refill Unit, Type RBA4 Single Barrel Standard Speed, 400E A, 8.3 kV, Glass Epoxy, 7.62 in L x 2.2 in W

Application

Load Interrupter Switchgear, Power Transformers, High Voltage Capacitors, Circuits and Pad Mounted Transformers Applications

Standards

IEEE C37.41

Features

  • A replaceable refill unit, comprising the current responsive element and the arc de-ionizing and extinguishing boric acid sold filler material
  • All contained within a high strength glass epoxy tube and with end connections for interfacing with the fuse holder
  • The fuse holder comprises a high strength glass epoxy tube and cast high conductivity end connections
  • The fuse holder assembly also includes the spring and shunt assembly which is pre-loaded when a fuse holder is charged with a refill unit
  • A reusable mounting to interface the loaded fuse holder assembly into the protected circuit
  • The mounting comprises the live parts, a pair of assembles that interface with and securely support the fuse holder
  • A non-disconnect mounting permanently mounts the fuse holder containing the refill with tension type fuse clips or bolted connections until it is completely removed
  • The disconnect mounting permits a fuse to be opened, closed or even lifted out of the mounting once it is opened
  • An insulated stick with a hook on the end of it is used to perform the opening and closing functions in a disconnect mounting
  • The insulated stick is referred to as a switch stick

Specifications

Amperage Rating:400E A
Country of Origin:DO
Dimensions:7.62 in L x 2.2 in W
Material:Glass Epoxy
Voltage Rating:8.3 kV
