AA-5201 ISO

Name: AA-5201 ISO
Brand: Isostatic
SKU: AA-5201 ISO
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Isostatic

Manufacturer part number:

101834

CBT Inventory

Vendor Inventory

Availability:

Ships in 2-4 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

ISOSTATIC™

Description

ISOSTATIC™ Oilube® Sleeve Bearing, 4.504 in Bore, 5.2545 in OD, 5 in Width, 220 deg F, 2000 psi Maximum, 1200 sfpm Maximum Velocity, 50000 psi/sq-ft/min Maximum PV, SAE 841 Powdered Metal/Oil Impregnated Bronze Bearing

Application

For heavy loads at moderate speeds or light loads at high speeds

Standards

Conflict Minerals Compliant | DFARS Compliant | REACH Compliant | RoHS Compliant

Features

SAE 841-copper (87 to 90%), tin (8 to 9%), carbon and other elements
Powdered metal bronze providing interconnected reservoirs for oil
Self-lubricating - when in motion oil rises to the surface for lubrication and restores itself when at rest
Effective in temperature range of 10 to 175 deg F with standard oil
Standard tolerances vary by size

Specifications

Bearing Material:	SAE 841 Powdered Metal/Oil Impregnated Bronze
Bore Diameter:	4.504 in
Country of Origin:	US
Maximum Pressure:	2000 psi
Maximum PV Rating:	50000 psi/sq-ft/min
Maximum Velocity:	1200 sfpm
Outside Diameter:	5.2545 in
Temperature Rating:	220 deg F
Width:	5 in
