ABC-V-1-R BSF

Name: ABC-V-1-R BSF
Brand: Bussmann
SKU: ABC-V-1-R BSF
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Bussmann

Manufacturer part number:

ABC-V-1-R

CBT Inventory

Vendor Inventory

Availability:

Expected Leadtime 24 days

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Bussmann

Type

Electronic

Description

Fast-acting, ceramic tube 1/4" x 1-1/4" ferrule fuse designed to UL 248-14 for overcurrent protection of electronic circuits. Install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation. Eaton's ABC fast-acting, ceramic body tube 1/4" x 1-1/4" fuses are designed with higher interrupting ratings and voltage ratings to UL 248-14 for overcurrent protection of electronic circuits. This is a RoHS compliant fuse. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation.

Bussmann Fast Acting Fuse, Electronic, Indicating/Non-Indicating: Non-Indicating, 1 A, 250 VAC, 35 A Interrupt, 4 hr at 100% Response, Ceramic Tube, 1/4 in Dia Body Size

Application

Electronic Circuit Applications

Standards

CE Certified

Features

Package Type: Standard
Melting (L2T): Typical pre-arc: 0.431
Notes: Ceramic body allows for higher amp/volt rating combinations.
Resistance: Typical DC cold: 0.195 ohms
Connection Type: Ferrule End x Ferrule End
Width: 1.375 in
Weight: 0.001 lbs
Length: 1.625 in
Height: 0.3125 in
Used With: Axial leads- copper tinned wire
Voltage Drop: Typical: 0.3 mV
Indicator: Non-Indicating

Specifications

Amperage Rating:	1 A
Body Size:	1/4 in Dia
Country of Origin:	CN
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	35 A
Material:	Ceramic Tube
Response Time:	4 hr at 100%
Voltage Rating:	250 VAC
