AFB3013IIIZBK HWD

Product Details

Manufacturer part number:
AFB3013IIIZBK
CBT Inventory
0
Vendor Inventory
Loading...
CBT - CINCINNATI
0
CBT - SPRINGBORO
0
CBT - SIDNEY
0
CBT - LEXINGTON
0
CBT - LOUISVILLE
0
Availability:
Ships in 4-6 days.
Estimated dates are contingent upon manufacturer stock.
Price on Request

Description

Brand Name

Wiring Device-Kellems

Type

Deep Pre-Wired Raised Standard

Description

The Hubbell® AFB series of recessed, stamped steel boxes are suitable for the majority of raised floor applications providing the flexibility, accessibility, capacity and depth profiles needed. These multi-service boxes are available in four or 8 gang options in a variety of power configurations. They utilize Hubbell® modular screw type plates and open systems modular connectivity face plates for delivering power, voice and data. A single reversible metallic cover/flange assembly mounts to all box sizes and has been designed with a large cable door to provide ample room for exiting cords.
Wiring Device-Kellems Access Floor Box, Deep Pre-Wired Raised Standard, Series: AFB301, 4 Gangs, 1/2 to 1-1/4 in Knockout, Surface Mounting, 29.5 cu-in Capacity, Stamped Steel, Galvanized, Black, 10 in L x 10 in W x 4 in H

Application

Used in environmental air handling spaces other than ducts or plenums

Standards

RoHS Compliant | UL Listed

Features

  • Reversible 1-piece cover/flange allows provision for carpet inlay
  • Adjustable hinged clamping arm simplifies installation
  • Delivers power and voice/data to the end user at floor surface level for easy plug-in accessibility and "plug and play" administration
  • Provides for maximum wire capacity
  • Hinged clamping arms provide easy installation from above without having to remove the cover
  • Utilizes Hubbell modular screw type plates and open systems modular connectivity face plates to deliver power and voice/data to the end user
  • All raised floor boxes use the same cover to provide a consistent appearance
  • Unpopulated gang

Specifications

Capacity:29.5 cu-in
Color:Black
Country of Origin:CA
Dimensions:10 in L x 10 in W x 4 in H
Finish:Galvanized
Knockout Size:1/2 to 1-1/4 in
Material:Stamped Steel
Mounting Type:Surface
Number of Gangs:4
Series:AFB301
